Industrial Jib

Industrial Jib - The lift truck jib will allow a worker to be able to shift their heavy heaps overtop of obstacles or obstructions on roofs, raised platforms, and decks. They can be used so as to reach the second and even third level building platforms so as to transfer or pick up loads at places which are still under construction. Fork truck jibs are utilized to deliver trucks and flatbed trailers, to laminate wood and suspend trusses. Jibs are even usually used for reaching over scaffolding for masonry work.

Each and every forklift jib attachment is equipped with two swivel hooks. One of the hooks can be manually connected on the base of the boom at whichever position while the second hook remains connected at the end of the jib. This enables the person operating it to carry stuff that have two hook points. Depending on the size of the model, each hook is rated at either 4000 or 6000 lbs. It's possible to utilize either one hook or even two to be able to carry a load. The individual operating it must be certain that the entire weight of the jib and the load does not go beyond the rated capability of the jib as shown on the load chart for that extended or retracted position.

Jib attachments are made in order to be used on industrial lift trucks, extendable-reach lift trucks, or even on rough terrain straight-mast lift trucks. Forklift jib cranes install onto the forklift through inserting two forks into the fork pockets. The back of the jib crane then seats towards the rear of the fork and a security chain wraps the forklift carriage to hold it into place.

Jib Boom Forklift Attachment Load Capacity

The most load capacity for forklift jibs in both the extended or retracted positions vary beginning from 1935 lbs up to 6000 pounds. It's a good suggestion to ask a material handling specialist about the restrictions for your particular application. The load capacity rankings are really used for the jib itself and not the forklift or the maximum load that can be lifted safely utilizing a certain forklift. It is very important remember that whenever any accessories like for example a lift truck jib are fitted to the lift truck, the new center of gravity made by the attachment will decrease the general lift capability of the forklift. There are instructions obtainable which offer information on the way to correctly calculate these load limits.

Fork Trucks & Fork lift Attachment Safe Usage

Before utilizing a lift truck jib, ensure that it is properly secured to the forklift with hooks and shackles. Always double check to verify that the screw pins are tight. It is very important to also be sure that the freight calculations have been done correctly. Bear in mind to take into consideration the fact that rated capacities occasionally lessen when the boom is in a raised position, every time the boom is fully extended with telehandlers or each time the mast is slanted forward.

Vital suggestions whenever using an adjustable jib is not to ever pull a load using this type of accessory. These kinds of attachments are really just meant for vertical raising. Additionally, avoid letting the load sway. Use extreme caution each time a load is carried so as to avoid tipping over the truck.
